50kN Offshore Pneumatic Air Tugger Winch Explosion-Proof Ship Hatch Cover Air Winch

Customization:	Available
After-sales Service:	Free Parts, Online Guidance
Warranty:	Supply

Basic Specifications

Model NO.

EW-HPW

Type

Pneumatic Winch

Driven Type

Pneumatic Winch

Speed

Fast

Tonnage

5T

Pulling Capacity

2-20ton

Working Pressure

0.69-5MPa

Feature

Explosion-Proof

Certification

GS, CE

Origin

China

Product Description

10t / 50KN Offshore Pneumatic Air Tugger Winch - Explosion-proof solution for ship hatch covers, pulling, and lifting operations.

Pneumatic winch is powered by a piston pneumatic motor, available in manual or remote operation modes. Known for high efficiency and safety, it is ideal for land and offshore drilling, mining, and maritime environments where flammable gases are present.

Primary Applications

Land & Offshore Drilling Platforms
Coal & Mining Industry Operations
Foundry & Chemical Industries
Pharmaceutical & Nuclear Power Plants
Metallurgical & Automotive Machining

Key Advantages

Explosion-proof: Safe for dangerous environments
Compact Design: Suitable for small workspaces
Low Maintenance: Fewer parts and long service life
Lightweight: Portable and easy to operate

Technical Parameters

No.	Parameter Item	Specifications (EWPW-5×48)
1	Rated Air Intake Pressure	0.8 MPa
2	Max. Lifting Force	5 kN
3	Max. Lifting Speed	48 m/min
4	Air Motor Rated Power	2.6 kW
5	Number of Cylinders	6
6	Drum Diameter / Width	180mm / 200mm
7	Wire Capacity / Diameter	60m / 8mm
8	Net Weight	116 kg

Our pneumatic winches feature adjustable speeds and quick installation. We have further developed remote electronic and air-control brake systems. These combine regular braking with advanced control systems to ensure remote operations are simple, safe, and highly reliable.

Frequently Asked Questions

Q1: Why is a pneumatic winch safer in explosive environments?

A1: Unlike electric winches, pneumatic winches are powered by compressed air, eliminating the risk of electrical sparks, making them naturally explosion-proof.

Q2: Can the speed of the winch be adjusted?

A2: Yes, the speed is infinitely variable and can be easily adjusted by controlling the air intake volume.

Q3: What maintenance is required for the air motor?

A3: Regular lubrication through an air line lubricator and ensuring the air supply is dry and clean are the primary maintenance needs.

Q4: Is remote control available for this model?

A4: Yes, we offer configurations for both remote air-control and remote electronic-control air-break brake systems.

Q5: What is the standard air pressure for operation?

A5: The rated air intake pressure for optimal performance is typically around 0.8 MPa, though it can operate within a 0.69-5MPa range depending on specific needs.
