Ltd-P Material Lifting Wire Rope Pulling Hoist

1 / 5

Ltd-P Material Lifting Wire Rope Pulling Hoist

Customization:	Available
Application:	Man-Riding
Type:	Electric Hoist

Send Inquiry

Product Description

LTD-P Material Lifting Wire Rope Pulling Hoist

Endless passenger elevation (man-riding) hoist designed for unlimited rope lengths for lifting and lowering personnel. Capacities range from 500kg to 1000kg at speeds of either 9 or 18 m/min.

This unlimited cable passenger lifting hoist is a versatile solution suitable for a wide range of applications. Its compact and lightweight design, combined with unrestricted wire rope lengths, allows for unlimited lifting heights and traction lengths.

Technical Specifications

Model

LTD-P

Sling Type

Wire Rope

Lift Speed

9/18m/Min

Certification

CE, TUV

Voltage

380V (415V/220V)

Frequency

50Hz/60Hz

Capacity

500kg - 1000kg

HS Code

8425110000

Features & Benefits

Robust die-cast aluminium housing ensures low dead-weight and high rigidity.
Hardened steel gearing and drive sheave for durability.
Universal attachment via central 16mm load pin or M10 screws.
Motor protection rated to IP55 as standard.
Standard operating voltage: 380V, 3ph, 50Hz (Customizable).
Control Voltage: 24V (mobile) or 42V (stationary).
Standard thermal overload protection device fitted to motor.
Nitrided steel drive sheave (70 HRC) ensuring low wear.
High-efficiency synthetic oil for temperatures from -40°C to 70°C.
Standardised components for easy maintenance and access.

Main Parameters of LTD Series Hoist

Model	Capacity (kg)	Lifting Speed (m/min)	Rope Diameter (mm)	Motor (kW)	Weight (kg)
LTD50-8P9	500	9	8.3	1.1	46
LTD50-8P18	500	18	8.3	2.0	47
LTD63-8P9	600	9	8.3	1.5	48
LTD63-8P18	600	18	8.3	2.2	49
LTD80-9P9	800	9	9	1.8	50
LTD80-9P18	800	18	9	3.0	53
LTD100-10P9	1000	9	10.2	2.2	51
LTD100-10P18	1000	18	10.2	4.0	62

*Voltage and frequency are available upon request.

Safety for Passenger Elevation

Compliant with DIN EN1808 requirements, each hoist for passenger elevation features an independent safety rope system. All safety components are TUV certified.

Flexible Attachment

Attachment points in housing corners allow flexible installation with screws or pins.

Safety Lowering Mechanism

Manual release of the electric-mechanical brake ensures safe lowering during power failure.

Inner Overload Mechanism

Hoist stops rising if load exceeds limits to prevent structural damage.

Operational Counters

Integrated recording of operating hours and number of starts for maintenance tracking.

Fall Arrester Systems

Overspeed Fall Arrester (OSL) Trips automatically when lowering speed exceeds 30m/min. Hardened steel jaws stop movement within centimeters.

Anti-tilting Fall Arrester (LSF) Trips automatically if the platform tilt angle exceeds 5°, immediately clamping the safety rope.

Dimensions

Frequently Asked Questions

What is the lifting capacity of the LTD-P series?

The capacity ranges from 500kg up to 1000kg, depending on the specific model selected (LTD50 to LTD100).

Is this hoist suitable for personnel lifting?

Yes, the LTD-P series is specifically designed for passenger elevation (man-riding) and complies with DIN EN 1808 safety requirements.

What certifications does the hoist have?

The product is fully certified by the independent inspection institute TUV and carries the CE mark.

How does the hoist handle power failures?

It features a manual safety lowering mechanism that allows the electric-mechanical brake to be released by hand for a controlled descent.

What are the available operating voltages?

The standard operating voltage is 380V, 3ph, 50Hz, but other voltages such as 415V or 220V are available upon request.

What safety devices are included for passenger elevation?

Standard safety features include thermal overload protection, overspeed fall arresters (OSL), anti-tilting arresters (LSF), and an overload cut-out system.
