Ltd-P Material Lifting Wire Rope Gondola Hoist

Customization:	Available
After-sales Service:	Engineer Oversea Service, Online
Warranty:	12 Months

Send Inquiry

Product Description

📋

Basic Information

Model NO.

LTD-P

Application

Man-Riding

Type

Electric Hoist

Sling Type

Wire Rope

Lift Speed

9/18m/Min

Maximum Lifting Height

Customer's Request

Certification

CE, TUV

Condition

New

Voltage

380V (415V/220V)

Frequency

50Hz/60Hz

Transport Package

Cardboard Box

HS Code

8425110000

⚙️

Product Description

Endless passenger elevation (man-riding) hoist designed for use with unlimited rope lengths for lifting and lowering personnel. Capacities range from 500kg to 1000kg at speeds of 9 or 18 m/min.

The LTD-P Series unlimited cable wire rope passenger lifting hoist is a versatile solution suitable for unlimited applications. The rope is not connected, making the unit compact, lightweight, and easy to handle. Unrestricted wire rope lengths make it possible to utilize unlimited lifting heights and traction lengths.

✨ Features and Benefits

✔ Robust die-cast aluminium housing ensures low dead-weight and rigidity.
✔ Gearing and drive sheave fabricated from hardened steel.
✔ Universal attachment via central 16mm load pin or M10 screws.
✔ Motor protection rated to IP55 as standard.
✔ Control Voltage: 24V for mobile and 42V for stationary units.
✔ Integrated thermal overload protection device.
✔ Certified by independent inspection institute (TUV).
✔ Special nitrided steel components guaranteeing low wear.
✔ Fully-synthetic oil for efficiency in temperatures from -40°C to 70°C.

📊

Technical Parameters

Model	Capacity (kg)	Lifting Speed (m/min)	Rope Diameter (mm)	Motor (kW)	Weight (kg)
LTD50-8P9	500	9	8.3	1.1	46
LTD50-8P18	500	18	8.3	2.0	47
LTD63-8P9	600	9	8.3	1.5	48
LTD63-8P18	600	18	8.3	2.2	49
LTD80-9P9	800	9	9.0	1.8	50
LTD80-9P18	800	18	9.0	3.0	53
LTD100-10P9	1000	9	10.2	2.2	51
LTD100-10P18	1000	18	10.2	4.0	62

* Voltage and frequency are available upon request.

🛡️

Safety for Passenger Elevation

In accordance with DIN EN1808 requirements, every hoist used for passenger elevation must feature a safety system on an independent safety rope. These safety systems comply with "Safety requirements on suspended access equipment" and are certified by TUV.

Flexible Attachment Points
Corners of housing available for screws or pins.

Safety Lowering Mechanism
Manual release for power failure situations.

Overspeed Fall Arrester (OSL)

Trips automatically when lowering speed exceeds 30m/min. Stops movement within centimeters.

Anti-tilting Fall Arrester (LSF)

Trips automatically when the platform angle exceeds 5°, immediately stopping movement.

📐

Dimensional Specifications

💡

Frequently Asked Questions

What is the maximum lifting capacity of the LTD-P series?

The LTD-P series offers a lifting capacity ranging from 500kg up to 1000kg, depending on the specific model selected.

Is this hoist safe for transporting personnel?

Yes, the LTD-P is specifically designed for passenger elevation (man-riding) and complies with the safety requirements of the DIN EN 1808 standard.

How does the hoist handle power failures?

The hoist is equipped with an electric-mechanical brake that can be manually released, allowing for a safe and controlled lowering of the load or platform in the event of a power outage.

Is the lifting height limited by the device?

No. Since it is an "endless" hoist, it is not limited by the length of the rope wound on a drum, allowing for virtually unlimited lifting heights.

What voltage options are available for the motor?

The standard operating voltage is 380V/3ph/50Hz, but customized options such as 220V or 415V and 60Hz frequency are available upon request.

What safety devices are included for passenger elevation?

The hoist utilizes overspeed safety fall arresters (OSL) and anti-tilting safety fall arresters (LSF) to ensure maximum safety during elevation.
